Shinwin MS160 60H Mid Drive Motor | 72V 12KW Peak | IP67 E-Bike & E-Motorcycle

Shinwin MS160 60H — High-Performance Mid Drive Motor for Electric Bikes & Motorcycles

Engineered for riders who demand serious power, the Shinwin MS160 60H delivers a peak output of 12 kW at 72V — enough to propel your build to 105 km/h. With IP67 waterproofing and a compact φ182×186 mm form factor, this motor is built for both street and off-road performance.

Key Specifications

• Motor Size: φ182 × 186 mm
• Motor Weight: 8 KG
• Color: Dark Black
• Installation Position: Mid Drive
• Rated Voltage: 72V
• Rated Power: 6.0 kW | Peak Power: ~12 kW
• Rated Torque: 16.7 N·m | Peak Torque: 64 N·m @ 450A peak phase current
• Rated Speed: 3,400 RPM (≈95 km/h) | Peak Speed: 3,800 RPM (≈105 km/h)
• Maximum Efficiency: ≥90%
• Transmission Ratio: Motor 1:1 / Vehicle 1:4.285
• Number of Pole Pairs: 5
• Position Sensor: Magnetic Encoder
• Temperature Sensor: NTC10K (rated to 200℃)
• Controller: FOC 72V 200A / 450A
• Protection Grade: IP67 (fully waterproof)
• Transmission Form: Direct Drive

Why Choose the MS160 60H?

Whether you're converting a performance e-bike or building a custom electric motorcycle from scratch, this motor's direct-drive mid-mount design delivers smooth, efficient torque transfer with minimal drivetrain loss. The FOC controller ensures precise throttle response at every RPM, while IP67 protection means you can ride in the rain without hesitation.

Dimensions

Performance Curve
