Shinwin MS160 72V 5KW Mid Drive Motor | 9kW Peak | IP67 Waterproof

Shinwin MS160 50H — 72V 5KW Mid Drive Motor

Built for riders who demand serious power. The MS160 50H delivers 5kW rated output with peaks up to 9kW, housed in a compact mid-drive format that transforms any electric bicycle or motorcycle build into a high-performance machine.

Key Specifications

• Motor Size: φ182 × 176 mm
• Motor Weight: 11 KG
• Color: Dark Black
• Installation Position: Mid Drive
• Rated Voltage: 72V
• Rated Power: 5.0 kW | Peak Power: ~9 kW
• Rated Torque: 9.5 N·m | Peak Torque: 40 N·m
• Rated Speed: 5000 RPM | Peak Speed: 7000 RPM
• Maximum Efficiency: ≥90%
• Pulley Ratio: 1:3.44 | Sprocket Ratio: 14:41
• Number of Pole Pairs: 5
• Position Sensor: Magnetic Encoder
• Temperature Sensor: PTC
• Controller Line Current: 150A
• Controller Phase Current: 405A
• Protection Grade: IP67 (Fully Waterproof)

Why Choose the MS160?

• 🔋 Extreme Torque: 40 N·m peak torque for powerful hill climbing and off-road performance
• ⚡ High Efficiency: ≥90% efficiency minimizes heat and extends battery range
• 🛡️ IP67 Waterproof: Fully sealed for all-weather, all-terrain riding
• 🎯 Precision Control: Magnetic encoder + PTC temperature sensor for safe, smooth operation
• 🔧 Mid Drive Advantage: Optimal weight distribution for superior handling
